SG-3000CNC Multi-function CNC machining center

China SG-3000CNC Multi-function CNC machining center supplier
SG-3000CNC Multi-function CNC machining center supplier SG-3000CNC Multi-function CNC machining center supplier SG-3000CNC Multi-function CNC machining center supplier SG-3000CNC Multi-function CNC machining center supplier SG-3000CNC Multi-function CNC machining center supplier SG-3000CNC Multi-function CNC machining center supplier

Large Image :  SG-3000CNC Multi-function CNC machining center

Product Details:

Place of Origin: china
Brand Name: KM
Model Number: SG-3000CNC

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Regular export packing
Delivery Time: 15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5 Pieces per Month
Contact Now
Detailed Product Description
Machine Size: 4.7 Mx2.2 Mx2.8 M Y Axis: 30m/min
Z Axis: 30m/min X Axis: 0.75 KW

SG-3000CNC Multifunctional CNC Machining Center



SG-3000CNC Multi-function CNC machining center



Product introduction

High precision three-axis CNC drilling and milling machine, using imported CNC positioning system, one clamping can achieve 180 degrees of rotation (0 degrees.+90

-90 degrees three plane) drilling and milling processing, especially suitable for all kinds of aluminum doors and Windows keyhole processing and all kinds of special-shaped aluminum profile of the multi-plane precision drilling and milling processing.

Main technical parameters

1, itinerary...... X axis........................................ 3000mm

Y axis................ 0 ° = 400 mm / 90 ° / - 90 ° = = 200 mm to 200 mm

Z axis................ 0 ° = 200 mm / 90 ° / - 90 ° = = 150 mm to 250 mm

2, speed...... Y axis....................................... 30m/min

Z axis....................................... 30m/min

X axis....................................... 80m/min

3, positioning accuracy.. X axis............................................ + / - 0.05

Y axis............................................ + / - 0.02

Z axis............................................ + / - 0.02

4. Servo motor... X axis............................................. 1.5 KW

Y axis.......................................... 1KW

Z axis......................................... 1.5 KW

A axis........................................ 0.75 KW

5, electric spindle.... Spindle power.................................... 6KW

Spindle speed.............................. 18000/min

Spindle taper................................. Ø 16 mm

6, Total power machine Total power... 12.5 KW

7, machine power supply... 3phases 380V/50HZ

8, machine size LXWXH... 4.7 mx2.2 mx2.8 m

9, machine weight... 1800kg



SG-260CNC

Multi-functional nc machining center



High precision triaxial numerical control drilling and milling machine, imported CNC positioning system, a clamping can realize rotate 180 degrees (0 degrees. + 90 degrees. Three plane – 90 degrees) processing of drilling and milling, especially suitable for all kinds of aluminum doors and Windows lock processing and various special-shaped aluminum surface precision drilling and milling.

ravel distance X axis 1000mm 2600mm 3000mm
Y axis 0°= 400 mm 90°= 200mm -90°= 200mm
Z axis 0°= 200mm 90°= 150 mm -90°= 250mm
speed X axis 30m/min
Y axis 25m/min
Z axis 25m/min
Positional accuracy X axis ±0.05
Y axis ±0.02
Z axis ±0.02
Servo motor X axis 1.5KW
Y axis 0.4KW
Z axis 0.4KW
spindle Spindle power 3KW
Spindle speed 18000/min
Spindle taper Ø16mm
Tooling charger Tooling capacity
Total power 6KW
cutting cooling atomization cooling
controller undetermined
Power 3phases380V/50HZ
Air pressure 0.6-0.8Mpa
weight   860kg 1200kg 1500kg
Overall size LXWXH 2.4mX1.5mX1.8m 4mX1.5mX1.8m 4.5mX1.5mX1.8m
