SG-D300 Thread repair precision saw

Certification
Good quality aluminum processing machine for sales
I'm Online Chat Now

SG-D300 Thread repair precision saw

China SG-D300 Thread repair precision saw supplier
SG-D300 Thread repair precision saw supplier SG-D300 Thread repair precision saw supplier SG-D300 Thread repair precision saw supplier SG-D300 Thread repair precision saw supplier

Large Image :  SG-D300 Thread repair precision saw

Product Details:

Place of Origin: china
Brand Name: KM
Model Number: SG-D300

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Regular export packing
Delivery Time: 15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5 Pieces per Month
Contact Now
Detailed Product Description
Machine Dimension: 6500mmX1300mmX1860mm Machine Weight: 1800kg

SG-D300

Thread repair precision saw



SG-D300 Thread repair precision saw





























The equipment adopts the concept of the design of the dragon gate. It is applied to the drilling, milling and tapping of various industrial steel components. The four axis adopts high precision linear guide and ball screw, high speed precision. A single clip can be used for machining of multi-surface machining and arbitrary Angle of arc. Built-in atomization cooling and cutting fluid circulation cooling, according to different processing requirements choose different cooling, automatic door implement fully enclosed processing and low noise, automatic waste recycling, energy conservation, environmental protection, create a comfortable working environment.







Technical Parameters

voltage 380V/50HZ cutting size 90°=300mmX170mm
Total power 8.2KW 45°=200mmX140mm
motor 2X4KW cutting angle 45°-90°
blade rotary speed 2840r/ min saw blade Ø600mmX38X4.4X144T
positioning mode manual, digital display blade feeding speed 0-10m/min
positioning tolerance ±0.02 mm cutting length 460mm-5200mm
tilting mode pneumatic cylinder air pressure 0.6-0.8Mpa
Tilting tolerance ±3· cooling mist cooling
control mode manual PLC 14p/24p
machine dimension 6500mmX1300mmX1860mm machine weight 1800kg
