SG-S500K CNC double-head cutting saw (after cutting)

Certification
Good quality aluminum processing machine for sales
I'm Online Chat Now

SG-S500K CNC double-head cutting saw (after cutting)

China SG-S500K CNC double-head cutting saw (after cutting) supplier
SG-S500K CNC double-head cutting saw (after cutting) supplier SG-S500K CNC double-head cutting saw (after cutting) supplier SG-S500K CNC double-head cutting saw (after cutting) supplier SG-S500K CNC double-head cutting saw (after cutting) supplier SG-S500K CNC double-head cutting saw (after cutting) supplier

Large Image :  SG-S500K CNC double-head cutting saw (after cutting)

Product Details:

Place of Origin: china
Brand Name: KM
Model Number: SG-S500K

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Regular export packing
Delivery Time: 15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5 Pieces per Month
Contact Now
Detailed Product Description
LXWXH: 5800mmX1700mmX1750mm Machine Weight: 1850kg

SG-S500K CNC double-head cutting saw (after cutting)









Product Introduction
This machine is mainly used to cut various aluminum alloy profiles, especially suitable for aluminum casement window profiles. The two heads can be manually cut at any angle from 45 degrees to 90 degrees. It adopts a closed-loop high-precision CNC positioning system and can be connected to ERP office software. , Realize error-free intelligent cutting; simple and convenient operation, stable operation and high precision!



1,机器电源power.....................................3相380V/50HZ

2,机器总功率Total power................................................ 6.2KW

3,锯片电机功率motor power ..................................2X3KW

4,锯片转速blade rotary speed...........................2840r/ min

5,定位方式Positioning way...............................................数控定位

6,控制方式..........................................................人工智能输入

7,定位精度positioning tolerance..........................±0.1 mm

8,角度精度Tilting tolerance...................................±3

9,切割尺寸(wxh)cutting size.......90°=150mmx185mm/45°=150mmX130mm

10,切割角度cutting angle....................................45°-90°

11,锯片尺寸saw blade.........................Ø500mmx30x4.2x120T

12,切割进给速度blade feeding speed.....................0-10m/min

13,切割长度cutting length...........................310mm-4500mm

14,机器气压air pressure...............................0.6-0.8Mpa

15,切削冷却cooling.........................雾化冷却mist cooling

16,机器尺寸(LXWXH).........................5800mmX1700mmX1750mm

16,机器重量machine weight.................................1850kg
