SG-L250D Multi-function End Milling Machine

SG-L250D Multi-function End Milling Machine

Product introduction: Product introduction

The machine is mainly used for cutting all kinds of aluminum profile end face milling, because the machine adopts the material of fixed gongs knife feed milling structure, easy and convenient operation, high accuracy, combination tool by knife sets installed together, according to the different combination of different series of aluminum customized tool, replace the convenient tool, cutting tool can make up and down before and after adjustment, make the operation simple and more efficient.

技术参数Technique data

1,机器电源Power.................................................3相380V/50HZ

2,电机功率 Blade motor..................................2 X3KW或1.1KW+3KW

3,锯片尺寸Blade size ..................................Ф250mm×25.4×3×120T

4,锣刀尺寸Miller size..............................Ø200mmX40X8X40T

5,切割进给速度Cutting feed speed.......................0-10m/min

6,电机转速Motor speed.................................2840r/ min

7,刀具水平调节Level adjustment..........................0～100mm

8,刀具垂直调节Vertical adjustment.........................0～150mm

9,机器总功率Total power..................................................6.2KW

10,工作台尺寸(LXWXH)Worktablesize...............400mmX350mmX150mm

11,刀具轴长MinCutting length..............................150mm

12,切削精度Cutting precision ...........................................±0.1

13,切削冷却Cutting cooling..............................雾化冷却

14,机器气压Max power.................................０.6-0.8Mpa

15,机器尺寸(LXWXH)Overall size......................1680 mmx1000mmx1500mm

16,机床重量 weight.........................................................350Kg
